circular Saw Blades for ferrous metal

Tungsten carbided Circular Saw Blades for Metal-CSSB

cutting speed: 50m/min-120m/min.

tooth load: 0.05-0.1mm/tooth.

Special PVD coated tungsten carbide tipped saw blades designed for cutting stainless steel and titanium solid bars.

Grade: Industrial
Machines: High speed sawing machines
Materials: High carbon steel, stainless steel and titanium, solid material or thick-walled pipes
Applications: For sawing high carbon steel, stainless steel and titanium

Get a quote

Optional materials and processes(OEM/ODM Available)

Body: 80CrV2/SKS51
Tips: Tungsten carbide

Coating: PVD
Tension ring: Visible or concealed configuration

Typical Specification

Code	D mm	B mm	b mm	d mm	Z	Tooth Type	Pinholes
CSSB0240	240	1.8	1.5	32	60	TC	Custom
CSSB0250	250	1.5	1.3	32	54	TC	Custom
CSSB0251	250	1.5	1.3	32	72	TC	Custom
CSSB0252	250	1.5	1.3	32	80	TC	Custom
CSSB0253	250	2.0	1.7	32	54	TC	Custom
CSSB0254	250	2.0	1.7	32	72	TC	Custom
CSSB0255	250	2.0	1.7	32	80	TC	Custom
CSSB0256	250	2.0	1.8	32	54	TC	Custom
CSSB0280	285	1.5	1.3	32	60	TC	Custom
CSSB0281	285	1.5	1.3	32	72	TC	Custom
CSSB0282	285	2.0	1.8	32	54	TC	Custom
CSSB0283	285	2.0	1.7	32	60	TC	Custom
CSSB0284	285	2.0	1.7	32	72	TC	Custom
CSSB0285	285	2.0	1.7	32	80	TC	Custom
CSSB0286	285	2.0	1.8	40	60	TC	Custom
CSSB0287	285	2.0	1.8	40	72	TC	Custom
CSSB0288	285	2.0	1.8	40	80	TC	Custom
CSSB0310	315	2.3	2.0	40	80	TC	Custom
CSSB0360	360	2.0	1.7	40	60	TC	Custom
CSSB0361	360	2.0	1.7	40	72	TC	Custom
CSSB0362	360	2.0	1.7	40	100	TC	Custom
CSSB0363	360	2.5	2.3	40	80	TC	Custom
CSSB0364	360	2.5	2.3	40	100	TC	Custom
CSSB0365	360	2.5	2.3	50	80	TC	Custom
CSSB0366	360	2.5	2.3	50	100	TC	Custom
CSSB0367	360	2.6	2.3	50	60	TC	Custom
CSSB0368	360	2.6	2.3	50	80	TC	Custom
CSSB0369	360	2.6	2.3	50	100	TC	Custom
CSSB0380	380	2.5	2.3	50	48	TC	Custom
CSSB0381	380	2.5	2.3	50	80	TC	Custom
CSSB0382	380	2.5	2.3	50	100	TC	Custom
CSSB0420	425	2.7	2.3	50	50	TC	Custom
CSSB0421	425	2.7	2.3	50	60	TC	Custom
CSSB0460	460	2.7	2.3	50	40	TC	Custom
CSSB0461	460	2.7	2.3	50	50	TC	Custom
CSSB0462	460	2.7	2.3	50	60	TC	Custom
CSSB0560	560	3.0	2.5	50	44	TC	Custom
CSSB0561	560	3.0	2.5	50	60	TC	Custom

Specifications can be tailored to meet customer requirements.
